TIANJIN HOYITE RUBBER PRODUCTS CO.,LTD.
Develivery time: 7 days
Model: HYT-150L Button type Electric, 6", 6S Crimping Range
Voltage: 380V 50HZ 3Phase or based on customer’s need .
Warranty : One year warranty on major components
HYT-150L Button type Electric, 6", 6S |
|
| Main Specification | |
| Crimper range | 1/4" -6" 6S (6-153mm) |
| Voltage&motor | 380V/4KW(5.5kw) |
| Opening without dies | 235mm |
| Hydraulic oil box | 160L |
| Dies of quantity | 20 sets(Includes a set of transition dies) |
| Systematic pressure | 31.5MPa |
| Largest pressure | 2500T |
| Quick change dies | Options(for dies from 6-51mm) |
| Optional accessories | No |
| Volume(LxWxH) | 91x59x121cm |
| Net weight | 850KG(1874lb) |
| Efficiency(reference) | 200pcs/Hour |
Plastic film wrapping;
Wooden packing;
The hydraulic oil tank is shipped empty, please fill it with No. 46 hydraulic oil to use the machine;
There are exposed wires left in the machine. Please replace them with new wires you prepared and use them with electricity.
