TIANJIN HOYITE RUBBER PRODUCTS CO.,LTD.
Develivery time: 7 days
Model: HYT-H150 Electric Button Type, 3''-6", 6S Crimping Range
Voltage: 380V 50HZ 3Phase or based on customer’s need .
Warranty : One year warranty on major components
| HYT-H150 Electric Button Type, 3''-6", 6S | |
| Main Specification | |
| Crimper range | 3" -6" 6S (76-153mm) |
| Voltage&motor | 380V/5.5kw |
| Opening without dies | 270mm |
| Hydraulic oil box | 180L(USE 170L) |
| Dies of quantity | 4 sets |
| Systematic pressure | 31MPA |
| Largest pressure | 1966T |
| Quick change tool | No |
| Optional accessories | No |
| Volume(LxWxH) | 142x90x100cm |
| Net weight | 1080KG(2381lb) |
| Efficiency(reference) | 150pcs/Hour |
Plastic film wrapping;
Wooden packing;
The hydraulic oil tank is shipped empty, please fill it with No. 46 hydraulic oil to use the machine;
There are exposed wires left in the machine. Please replace them with new wires you prepared and use them with electricity.
