HOYITE máquina grafar mangueras
PowerGrip Max is the go-to hydraulic hose crimping machine for heavy-duty applications. Engineered for strength and durability, this benchtop machine effortlessly handles high-pressure hoses with ease. With its robust construction and powerful crimping capabilities, achieve secure and reliable connections that meet the demands of the toughest industrial environments.
DX-68 Button type |
|
| Main Specification | |
| Crimper range | 1/4"-2" 4SP (6-51mm) |
| Voltage&motor | 380V(4KW)/220V(3KW) |
| Opening without dies | 114mm |
| Hydraulic oil box | 40L(USE 32L) |
| Dies of quantity | 10 sets |
| Systematic pressure | 31.5MPa/26.5MPa |
| Largest pressure | 400T |
| Quick change dies | Options |
| Optional accessories | Movable caster/Metal handle |
| Volume(LxWxH) | 80×53×87cm |
| Net weight | 220KG(485lb) |
| Efficiency(reference) | 200pcs/Hour |
Engarzar Cortar Rebajar
Manual 12 V Portátil
Taller Producción Servicio pesado
Alimentación lateral Tuerca y cable
Opciones Juegos de troqueles
